Product Description Description: Beaver Close Headroom Geared Girder Trolleys are used for applications where reduced headroom is required and are suited for heavier loads, higher suspension levels, or high use applications The units suit varying flange widths up to a maximum of 350mm with the simple addition or subtraction of spacers or nuts on a suspension pin These girder trolleys are lightweight, despite their robust all-steel construction and have been operationally tested to 150% of their rated capacity Note:-Beaver Close Headroom Geared Trolleys are not designed for passenger elevator applications and must not be used for this purpose. Selection and calculation of the proper beam construction is the responsibility of the user Features: Fully adjustable Hand chain features a special corrosion resistance zinc dichromate (gold) finish Anti-tilt blocks fitted as standard for additional safety Colour coded to match international WLL lifting standards Stainless steel ID plate for traceability Approved Standards: Complies to AS 1418.2 Specifications: Product Code 522005S Rated Capacity 0.5t Colour Code White Proof Load 7.35kN Minimum Radius Curve 0.8m Net Weight 6.5kg Q (mm) 35.5 Dimensions: Product Code 522005S Rated Capacity 0.5t A 245mm B 199mm C 187mm D 34mm E 30mm F 1.5-3mm G 24mm H 105mm I 79mm J 55mm L1 100mm M 50-152mm UPC: 9322297012018 Enquiry Tell A Friend
